SKU JLS-3-DHB · HS 8302.20.00
Four-bolt top-plate swivel with a hard polished PP wheel — black tread, white hub — and a side pedal brake that parks the wheel. The ball-bearing PP option of the JLS-3 plate range for warehouse trolleys, industrial machines and heavy equipment.
FOB Shenzhen / Nansha · MOQ 500 pcs · reply within 24 h
Samples: 2–3 pcs free for qualified distributors (freight collect).
| Material | PP | Caster Brake Type | No Brake Included, Swivel With Brake |
| Hub Width | 32 mm (1.26 in) | Base Plate Size | 93 × 61 mm (3.66 × 2.40 in) |
| Bearing Type | Ball Bearing | Wheel/Tread Hardness Rating | Hard |
| Surface Treatment | Polished | Applicable Industries | Heavy Industry & Specialized Equipment, Industrial Machine |
| Includes Thread Guards | No | Wheel Shape | Flat Type |
| Top Plate Thickness | 3.8 mm (0.15 in) | Feature | Durable, Wear resistance |
| Color | Black, White | Customized Support | ODM, OEM |
| Plate Size | 93 × 61 mm | Model Number | JLS-3-DHB |
| Brand Name | JLS |
Four-bolt top-plate swivel with a hard polished PP wheel — black tread, white hub — and a side pedal brake that parks the wheel. The ball-bearing PP option of the JLS-3 plate range for warehouse trolleys, industrial machines and heavy equipment.
A four-wheel trolley normally uses two swivel + two rigid casters so it tracks straight; use four swivel casters only where the equipment must move sideways in tight spaces.
